Optimizing Spark Job (spark-submit/shell)

This article is second from our series, optimizing the spark command, we usually use two types of spark commands, spark-submit and spark-shell, both of them take the same parameters and options, however the second is a REPL which is used to mainly do debugging. In this, we will see what parameters are important and how to set/calculate the values for better performance.

Let’s go!

Memory and Cores

The most important parameters in the command are memory and corers, both driver and executor have them and its very important to calculate them for best utilization.

Driver

Driver has two parameters driver memory and cores:

--driver-memory <value> --driver-cores <value>

The easiest for this is to use ~98% of memory and cores. For example, using 64GB memory and 32 virtual cores, to make the most of it we calculate like this:

--driver-memory 6200M --driver-cores 31

Executor

Executors have three parameters executor number, memory and cores:

--executor-memory <value> --executor-cores <value> --num-executors <value>

However, we can ignore the num-executors as it can be calculated based on the other two values. For example, using 10 core nodes with 64GB memory and 32 virtual cores, we have few scenarios:

Fat executor with 100% utilization:

--executor-memory 6400M --executor-cores 32

To calculate the number of cores is divide both with the same number 1 in this case then multiply it by the core nodes count, 1 * 10 = 10.

Thin executor with 100% utilization:

--executor-memory 800M --executor-cores 4

To calculate the number of cores is divide both with the same number 8 in this case then multiply it by the core nodes count, 8 * 10 = 80.

Unfamiliar with fat and thin executor words? Read Here!

For the sake of explanation, I used 100% utilization so we can see how we divide it by a factor, the suggested utilization is ~98%. Also, we did not consider memory overhead which should be subtracted from the 6400M/800M. Explained the importance of memory overhead later in this article.

Configuration

Spark commands have a parameter --conf, which has several configurations that need to be setup before submitting the job. These configurations can also be updated within the spark actual code (scala, python, etc). Here I will discuss the most important ones that usually cause issues.

Garbage Collection

--conf spark.executor.extraJavaOptions=<value>

Garbage collector configuration is done in extraJavaOptionsfor both driver and executor, the default is Parallel GC. And the most common problem is that job becomes very slow as the garbage collection process takes longer to empty up the space due to several reasons like memory management when process keeps persisting the data making it difficult for garbage collector.

It is recommended to start with the G1 GC garbage collector -XX:+UseG1GC which uses a new approach

Recommended Reading: Tuning Garbage Collection

Memory Overhead

--conf spark.executor.memoryOverhead=<value>

Memory overhead is also an important configuration, the total executor memory is defined by both –executor-memory and the memoryOverhead. By default, it is executorMemory * 0.10, with minimum of 384. Physical memory errors are usually because of low memory overhead. The value of memory overhead depends on the job, the more the parallel jobs the more overhead memory is needed, however, it is good to start with the default value.

Read Spark Docs!

Parallelism and Partition

--conf spark.default.parallelism=<value>
--conf spark.sql.shuffle.partitions=<value>

Setting up parallelism and partitions correctly helps in improving the job performance, they both are related to each other as the parallelism depends on the number of partitions and the value are set the same for both. The basic rule of thumb is the number of cores should be equal or multiple of the number of partitions.

Complete Spark Command Example

Using 10 core nodes with 64GB memory and 32 virtual cores with `~98%` utilization and a balanced configuration between fat and thin type:

/usr/bin/spark-submit --class class_path --driver-memory 6200M --driver-cores 31 --executor-memory 2700M --executor-cores 15 --num-executors 100 --conf spark.driver.extraJavaOptions=-XX:+UseG1GC --conf spark.executor.extraJavaOptions=-XX:+UseG1GC  --conf spark.sql.shuffle.partitions=300 --conf spark.executor.memoryOverhead=400M --conf spark.default.parallelism=300 jar_path

Explaining the command

• The values set here are just for the sake of example, it does not mean to use this setting for every job.

• Driver setting is pretty straight forward as mentioned earlier.

• Number of executors is set to a random number 100 as its calculated through the memory and core. The actual number of executors will be 2 * 10 = 20 as explained earlier (factor * number of core nodes).

• Each core node will have two executors with 2700M + 400M = 3100M (memory + overhead) and 15 VC (Total memory used by executor is 3100M * 2 = 6200M and similarly 30 VC).

• Total virtual cores used are 15 * 2 * 10 = 300 VC (VC used by single executor * number of executors in single node * total number of core nodes).

• Partitions and Parallelism both are set to 300 because the VC used are 300 (gives the maximum parallelism).

• Garbage collector -XX:+UseG1GC used as suggested above.


For more about the spark command? Read Spark Docs!
